【ZVB20回收|二手ZVB20】羅德與施瓦茨ZVB20回收網絡分析儀：儀器回收、二手儀器回收
ZVB矢量網絡分析儀
R&S ZVB矢量網絡分析儀適用于無源器件和有源器件的通用測量，它的頻率范圍有300KHz至8GHz和10 MHz 至20 GHz。R&S ZVB使矢量分析變得更加簡單，
特別是對于多端口器件和平衡器件的測量而言。由于它那全面的測量功能、出色的技術指標、快速的數據采集傳輸能力和強大的遠程控制能力，使得R&S ZVB成為研發和生成的理想設備。
ZVB矢量網絡分析儀
具備2/3/4個端口
多端口處理能力
每個端口都配有獨立的測量接收機和參考接收機
測試速度快，數據處理功能強大
ZVB矢量網絡分析儀
型號 描述
ZVB4 矢量網絡分析儀，300kHz~4GHz，2端口、3端口、4端口任選
ZVB8 矢量網絡分析儀，300kHz~8GHz，2端口、3端口、4端口任選
ZVB20 矢量網絡分析儀，10MHz~20GHz，2端口、4端口任選
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
聯系電話：
李琳 18676330086（**同號） QQ:120186103
專業回收、銷售、租賃、維修各類二手電子測量儀器！
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
Rohde&Schwarz ZVB20 20G矢量網絡分析儀|羅德與施瓦茨 10MHz至20GHz
品牌：羅德與施瓦茨 Rohde&Schwarz
The R&S®ZVB series of vector network analyzers covers the frequency ranges from 300 kHz to 4/8 GHz and from 10 MHz to 14/20 GHz. It has been designed for universal measurements on passive and active components. The R&S®ZVB series greatly simplifies vector network analysis especially for multiport measurements and measurements on balanced devices. Featuring comprehensive measurement functions, excellent specifications, high measurement and data transfer speeds and remote-control capability, the analyzers of the R&S®ZVB series are an ideal choice for both development and production applications. The compact versions of the 14 GHz and 20 GHz two-port models leave ample room for test setups in the lab, featuring a height of only 24 cm and a depth of 42 cm.
New multiport concept
◇ Instruments with two or four test ports – for multiport and balanced measurements
◇ Two internal sources (four-port models) – to provide RF and LO signals for mixer measurements by means of a single unit
◇ Capability to perform balanced measurements – to characterize balanced DUTs by their mixed mode S-parameters
◇ Optional automatic calibration units – to speed up calibration and avoid operator errors
Outstanding specifications
◇ 60001 points per trace
◇ Dynamic range better than 123 dB (typ. 130 dB)
◇ Power sweep range >50 dB
High speed
◇ Measurement time < 4.5 ms for 201 test points (frequency sweep)
◇ Switching time between channels < 1 ms
◇ Switching time between instrument setups < 10 ms
◇ Data transfer time < 0.7 ms (201 test points via RSIB)
◇ Simultaneous measurement of more than one DUT
Modern user interface
◇ Intuitive Windows-based operation via mouse
◇ Operation by means of hardkeys and softkeys
◇ Large number of channels, traces and setups that can be loaded simultaneously
品牌：羅德與施瓦茨 Rohde&Schwarz
The R&S®ZVB series of vector network analyzers covers the frequency ranges from 300 kHz to 4/8 GHz and from 10 MHz to 14/20 GHz. It has been designed for universal measurements on passive and active components. The R&S®ZVB series greatly simplifies vector network analysis especially for multiport measurements and measurements on balanced devices. Featuring comprehensive measurement functions, excellent specifications, high measurement and data transfer speeds and remote-control capability, the analyzers of the R&S®ZVB series are an ideal choice for both development and production applications. The compact versions of the 14 GHz and 20 GHz two-port models leave ample room for test setups in the lab, featuring a height of only 24 cm and a depth of 42 cm.
New multiport concept
◇ Instruments with two or four test ports – for multiport and balanced measurements
◇ Two internal sources (four-port models) – to provide RF and LO signals for mixer measurements by means of a single unit
◇ Capability to perform balanced measurements – to characterize balanced DUTs by their mixed mode S-parameters
◇ Optional automatic calibration units – to speed up calibration and avoid operator errors
Outstanding specifications
◇ 60001 points per trace
◇ Dynamic range better than 123 dB (typ. 130 dB)
◇ Power sweep range >50 dB
High speed
◇ Measurement time < 4.5 ms for 201 test points (frequency sweep)
◇ Switching time between channels < 1 ms
◇ Switching time between instrument setups < 10 ms
◇ Data transfer time < 0.7 ms (201 test points via RSIB)
◇ Simultaneous measurement of more than one DUT
Modern user interface
◇ Intuitive Windows-based operation via mouse
◇ Operation by means of hardkeys and softkeys
◇ Large number of channels, traces and setups that can be loaded simultaneously
